Flexible design

◆ Small size, light weight, support manual installation, reduce user installation and maintenance cost

◆ Multi-communication interface: RS485, GPRS(optional), Wifi (optional)

◆ DC breaker, easy to maintain and safe to use

◆ Convection without fan Digital DSP control technology

Efficient conversion

◆ Transformerless,max. efficiency is up to 98.1%

◆ Euro. efficiency is up to 97.6%

◆ Total current THD <2%

◆ Active and passive anti-islanding protection

◆ Continuously adjustable active power (0-100%) function

◆ CQC Gold Sun Certification

◆ TUV Certification

◆ SAA Certification

◆ CE Certification

AEP-8/10/12KS48P3

Model Name	AEP-8KS48P3AEP-8KS48P3		AEP-10KS48P3				AEP-12KS48P3
Battery input data
Battery Type	Lithium or lead acid battery
Rated battery voltage(V)	48
Maximum charging voltage(V)	≤60 (Configurable)
Maximum charge/discharge current(A)	190			210				250
PV input data
Maximum DC input power(kw)	16				20				24
Maximum DC input voltage(V)	1000
MPPT Operating voltage range(V)	200~800
Starting voltage(V)	150
Maximum input current(A)	18/18		36/18				36/18
MPPT number	2		2				2
AC output parameters (On-Grid)
Maximum output apparent power (KW)	8800	11000				13200
Rated output voltage(V)	400
Rated output frequency(Hz)	50/60Hz
Max output current(A)	13.3	16.7				20
Output power factor	~1 (-0.8 leading~+0.8 lagging)
AC output parameters(Off-Grid)
Rated output apparent power(VA)	8000	10000				12000
Maximum output apparent power(VA)	16000,15sec	20000,15sec				24000,15sec
Rated output voltage(V)	380/400
Rated output frequency(Hz)	50/60
Max output current(A)	13.3	16.7				20
Efficiency
Max efficiency(PV)	98%
Max efficiency(cell)	94.5%
Europe efficiency	97.5%
Protection
PV input reverse polarity protection	Yes
PV insulation resistance detection	Yes
Residual current detection	Yes
Output over current protection	Yes
Output short circuit protection	Yes
Output over voltage protection	Yes
Basic data
Operation temperature (°C)	-25~60
Storage temperature (°C)	-30~65
Relative humidity	0~95%
Working altitude (m)	≤4000
Cooling	Air cooling
Noise (db)	<55
Weight (Kg)	38
Size (width x height x depth) (mm）	475683256
Protection class	IP66
Topology	HF isolation (Battery side)
